Reactor Vessel

products

1) Reactor Vessels :-

High-Performance Process Reactors for Industrial Applications

APPLICATIONS

  • Chemical & Specialty Chemical Processing
  • Pharmaceutical & API Manufacturing
  • Petrochemical & Refinery Units
  • Resin, Polymer & Adhesive Production
  • Food & Industrial Processing

TECHNICAL SPECIFICATIONS

  • Capacity: 100 Liters to 50,000 Liters
  • Design Pressure: Vacuum to 25 Bar
  • Design Temperature:Up to 350°C
  • Material of Construction (MOC):SS304 / SS316 / SS316L / CS / Alloy Steel
  • Jacket Type: Limpet Coil / Conventional / Half Pipe
  • Agitator Type: Anchor / Paddle / Turbine / Helical
  • Drive System: Geared Motor / Top or Bottom Mounted
  • Insulation: Mineral Wool / Ceramic (Optional)
  • Surface Finish:Mirror / Matt / GMP Finish (for Pharma)

QUALITY & STANDARDS

  • Designed as per ASME Sec VIII Div 1, IS 2825, API standards
  • Advanced fabrication with NDT testing (RT/UT/DPT)
  • Hydro testing & dimensional inspection
  • Material test certificates & documentation provided
